China Factory Hydraulic Cylinder 3 Axle 35 Cubic Meter U Shape Dump Tipping Tipper Semi Trailer

Overall Dimension(L x W x H)(mm)

9000*2500*3700

Inner Dimension(L x W x H)(mm)

8200x2400x1500

Carrier Volume(m³)

27m³

Thickness

Bottom: 6mm, Side: 4mm

Lifting Type

HYVA lifting

Lifting System

Five ø125lifting cylinders, one piece of ø140 displacement cylinder

Tare Weight(KG)

7500—8000kg

Loading Weight( KG)

40000

Axle Brand

16TON Axle

Suspension system

Leaf spring suspension

Steel Spring

10/10/10 Heavy duty leaf spring suspension

Frame Beam

Main frame is height 400/500mm, Upper plate is 16mm, lower

plate is18mm,middle is8+6mm

Tire Type and quantity

12R22.5 12units

Traction Pin

50mm or 90mm

Spare Wheel Bracket

2 pieces

Tool Box

1 Unit

Landing Gear

Two-speed, manual operation, heavy duty landing gear,28t

Brake system

Dual Line braking system ,none ABS.

Electrical system

1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness)

Tail lamp with turn signal, brake light & reflector, side lamp etc.

One set 6-core standard Cable.

Painting

Color by customer’s requirement

Packing

Polish with wax before shipping

Delivery way

Transfer to China port, and carry by ro-ro ship, the freight cost

depends on the volume.

Delivery time

15 workdays after confirming order and receiving your deposit
