U Shape Dump Trailer
1. U shape dump trailer adopts a standardized and modular welding process, and standardized operations are carried out on the length of the welding seam, the position of the welding seam, and the reservation, to ensure the perfect welding standard of each trailer.
2. 100% of the whole trailer is made of full-thickness wear-resistant steel, which is more wear-resistant and anti-manufacturing.
3. Effectively solve industry problems such as welding cracking of tipper trailers, deformation of carriages, rapid tire wear, and unsynchronized lifting.
Product Details
The frame of the U shape dump trailer is made of a 16Mn beam plate. The U-shaped carriage has a low center of gravity, is clean and quick to unload, is not easy to overturn when lifted, and has a long service life.
Advantages of U shape dump trailer
1. U shape dump trailer is different from the design concept of a square cargo box. Through new structural design and high-strength box board, the self-weight is reduced based on ensuring the bearing strength and the transportation efficiency are effectively improved.
2. The bottom of the dump trailer is designed in an arc shape, and the center of gravity is lowered for safer driving.
3. The corners of the dump semi trailer adopt an arc-shaped transition, which is not easy to stick to the box when unloading, the unloading speed is faster, and the unloading residual rate is zero.
4. The bottom of the U shape dump trailer cargo box is an arc-shaped flexible structure, which relieves the impact on the bottom when transporting ore and prolongs the service life of the bottom plate.
More details
|
Overall Dimension |
9200mm x 2500mm x 3800mm |
|
(Lx W x H)(mm) |
8500mm x 2300mm x 1800mm or 35.15 cubic meter |
|
Inner Dimension |
I shaped mild alloy Q345B by automatically submerged |
|
Main beam |
arc welding 18 - 8+6 - 18mm |
|
Platform thickness |
10mm |
|
Side wall thickness |
8mm |
|
Hydraulic System: |
Full set of HYVA Hydraulic System |
|
Kingpin |
50mm |
|
Land gear |
28t |
|
axles |
Guangdong FUWA brand, 3*16T |
|
Track |
1840/1840/1840 |
|
Suspension: |
Mechanical Suspension |
|
Tire |
12R20 standard brand 12pcs |
|
Brake system |
30/30 type on each axle, Wabco brake valve |
|
Spare wheel carrier |
2 pcs |
|
Toolbox |
1 pcs |
|
Electrical System |
Chinese standard 24V lighting system |
|
Brake: |
Dual Lines Pneumatic Brake System. T30/30 Air Chamber; Parking Brake |
|
Brake air chamber |
Six big chamber |
FAQ
1. Q: What kind of payment do you accept?
A: We accept T/T and L/C; other payments are negotiable.
2. Q: What's your minimum order quantity?
A: One unit.
3. Q: What's your delivery time?
A: 30 days after receiving the deposit.
4. Q: What's the warranty time?
A: 12 months or 30,000 km from the date of shipment whichever comes first.
5. Q: What's your after-sale service?
A: We provide technical support for our u shape dump trailers and whole-life parts supply.
