20ft 40ft Skeleton Trailer Truck Trailer Chassis
Product Details
Features of 20ft 40ft Skeleton Trailer Truck Trailer Chassis
1. High and strong structural steel with tensile and high load capacity, 40 tons load capacity.
2. Heavy-duty mechanical spring brackets to meet high load requirement demands and manual poor
3. The length and width of the skeleton can be customized
4. Air suspension and bogie suspension are an option.
5. 8 unit twist locks for carrying 20ft container and 40ft container
We provide skeleton plate trailers with Q345 as the main material, which has the characteristics of high strength and strong rigidity. Other accessories are all well-known brands at home and abroad so the flatbed trailer has a longer service life and saves labor.
Specification of 20ft 40ft Skeleton Trailer Truck Trailer Chassis
| Dimension | 12.5m×2.5m×1.6m (Outside) |
| Payload | 50T |
| Tare weight | About 6.8T |
| Twist lock | 12 units |
| Main beam | Q345B carbon steel “H” beam |
| Frame Floor | The thickness is a 3mm pattern |
| Axle | 2 3 4 axles, FUWA/BPW brand |
| Landing Gear | JOST brand 28T lifting capacity with linkage speed |
| King Pin | 2.00 or 3.5-inch bolt-in kingpin |
| Suspension | Mechanical suspension or Airbag suspension |
| Leaf Spring | 90mm(W)*13/16mm(T)*10(Layer) |
| Tire | 12R22.5 |
| Accessories | One standard toolbox |
Application of 20ft 40ft Skeleton Trailer Truck Trailer Chassis
Skeleton semi-trailers can be used to transport containers, such as in logistics systems such as ships, ports, routes, expressways, transfer stations, bridges, tunnels, etc., and can also be used to transport dangerous goods tanks.
Our Advantage
1. Factory direct sales.
2. Our products can be customized for various needs. And customized unique company logo is available.
3. The factory adopts cutting-edge automation equipment. The steel is welded using an automatic submerged arc process, and the joints look perfect, stronger, and more durable than traditional manual methods.
4. The coating of the cover plate is more sustainable, corrosion-resistant, uniform, and smooth, and adopts sandblasting powder coating process.
