3 Axle Low Bed Trailer
Product Details
As a leading manufacturer and supplier of semi-trailers, Chengda Group offers a range of products designed to meet the needs of various industries. One of our most popular products is the 3 axle low bed trailer, which is widely used for the transportation of heavy and bulky goods.
Specification of 3 axle low bed trailer
| Dimension and Weight | |
| Overall Dimension(mm) | 18000x3000x1650mm |
| Working Deck Dimension(mm) | 8000x3000x1350mm |
| Platform thickness(mm) | 4mm |
| Main Beam | “H”main beam design,Q345B carbon steel,the height of the beam is 500 mm,upper plate is 16mm,down plate is 18mm, middle plate is 10 mm. |
| Wheelbase | 7,650mm+1,310mm+1,310mm |
| Payload | 60,000kg |
| Tare weight | 9,000kg |
| G.V.W.R. | 69,000kg |
| Function | To transport bulk goods or heavy equipment like loader or excavator |
| Running System | |
| Axle | 16Ton, ZY brand optional FUWA brand,one hundred fifty thousand Kilometers no need maintenance |
| Axle Number | Three |
| Tire | 1100R20, 16 pcs Taitong brand |
| Rim | 8.0*22.5 steel disc wheel, 10 holes ISO, 12 pcs |
| Suspension system | Common Mechanical Suspension |
| Steel Spring | 10/10/10/10 leaf spring with 90mm(W) *13mm(thickness) |
| Electrical System | Chinese standard 24V lighting system |
| Brake system: | Dual line pneumatic brake, SAE hose and connector,optional ABS |
| Brake air chamber | 6 units T30/30 spring brake chambers |
| Emergency relay valve | Wabco relay valve |
| Traction/King Pin | 2” and 3.5” removable Kingpin, bolted in type 500mm from the front face of the front bolster |
| Landing Gear | Zhenhua brand 28ton |
Why choose Chengda's 3-axle low-bed trailer?
The 3 axle lowboy trailer is designed to provide a solution for transporting oversized and heavy cargo that cannot fit on a regular trailer. The trailer is equipped with three axles, which help to distribute the weight of the load evenly, ensuring safe and stable transportation.
The low deck height of the 3-axle low bed trailer also facilitates the loading and unloading of heavy equipment such as construction machinery, cranes, and transformers. The trailer has a hydraulic ramp that can be lowered to the ground for easy loading and unloading.
3 axle lowboy trailers are available in different configurations to meet specific customer needs. We offer a wide choice of deck lengths, widths, and heights, as well as accessories such as side rails, container locks, and toolboxes.
Besides 3-axle lowboy semi trailers, Chengda Group also provides other semi-trailers, such as flatbed trailers, skeleton trailers, and tanker trailers. All of our products are designed and manufactured in compliance with international standards, ensuring high quality and reliability.
Overall, the 3 axle low bed trailer is the ideal solution for customers who need to transport heavy and oversized loads safely, reliably, and efficiently. With its low deck height, durable construction, and customizable options, it is a versatile and trusted choice for a variety of industries.
