3 Axles Quick Transport Container Skeleton Trailer
3 Axles quick transport Container Skeleton Trailer is very popular in the world. Our skeletal container trailer price is really good with high quality ensured. Come to Chengda trailer, you can customized container trailer you want....Chat Now
3 Axles quick transport Container Skeleton Trailer
3 Axles quick transport Container Skeleton Trailer is very popular in the world. Our skeletal container trailer price is really good with high quality ensured.
Come to Chengda trailer, you can customized container trailer you want.
3 axle 40ft container semi trailer
Axle brand and number
13TFuwa Brand, 3 units
50# or 90#
10/10/10 leaf spring suspension
The material of Main beam
The height of the beam is 500 mm, upper plate is14mm,down plate is 16mm, middle plate is 8mm.
Tyre and quantity
28T, double speed operation
3mm Checkered steel plate
Dual Line braking system, none ABS.
Brake air chamber
Four double and two single chamber
24V, 7 pin socket,One set 6-core standard Cable
Tail lamp with turn signal, brake light & reflector, side lamp etc
Spare tire carrier
Polish with wax before shipping
1. The 3 Axles quick transport Container Skeleton Trailer use through-going beam structure, has frame structure with flat type and goosen neck type, also has high integral strength, small weight, beautiful appearance, safe and reliable operation.
2. The skeleton skeletal container truck trailer chassis use advanced manufacture technology , makes automatic submerged-arc welding for vertical beam, use shot blasting treatment for intergral frame, removes welding stress effectively.
Packaging & Shipping
1. Main shipping way by Bulk Ship or RO-RO Ship with a tractor truck.
2. It can be shipped by Container. But the tail has to cut before shipping. It can be assembled by welding and bolts easy.
Our factory has BV, WMI, CCC, ISO9001 certifications.
The certifications pcs is attached as followings.
Equipment for side curtain wall high bed cargo semi trailer
If you have any questions, Pls feel free to contact me.
