Shacman 10 Wheeler Dump Truck
Product Details
The Shacman 10 wheeler dump truck adopts a fast gearbox with high transmission efficiency, small speed ratio step size, and wide speed ratio range, which can take into account oil economy and dynamic performance, and has strong adaptability to working conditions.
Features of Shacman Dump Truck
1. Shacman 10 wheeler dump trucks are based on international technical concepts, driving comfort, reliability, electronic level, and international level.
2. We have enough used trucks with long service life to meet your different requirements.
3. Shacman trucks are suitable for normal or bad road conditions, with low fuel consumption, combined with Mann and Steyr technologies.
4. We have 336hp to 420hp to choose from, the used dump truck can change the cab, and tires according to your needs.
5. Please provide your requirements, we can provide you with the best truck plan and choice of commercial shipping methods.
Application
1. Function: Dump trucks are mainly used to transport bulk goods (such as sand, soil, ore, and crops), and can also be used to transport finished products.
2. Main places of use: building materials factories, mines, construction sites, etc.
Specification of Shacman 10 Wheeler Dump Truck
| Model | SX33156V366 | |
| Max. running speed (km/h) | 85 | |
| Drive System | 8x4 | |
| Dimensions(L*W*H)(mm) | Overall | 10329x2490x3450 |
| Dump Body | 7400x2300x1500 | |
| Tipper thickness (mm) | Bottom 8, side 6 | |
| Hydraulic lifting system | HVYA front lifting | |
| Approach /departure angle (°) | 28/20 | |
| Kerb weight (kg) | 14600 | |
| Total mass (kg) | 31000 | |
| Wheelbase (mm) | 1800+3575+1400 | |
| Overhang (mm) (front/rear) | 1525/2054 | |
| Track width (mm) (front/rear) | 1939/1850 | |
| Engine | WP12.430E201(Weichai engine, Euro 2) | |
| Horsepower | 385 hp | |
| Ma. torque (N,m) | 2060 | |
| Displacement (L) | 11.596L | |
| Gearbox | 12JSD200T-B+QH50, FAST Gearbox | |
| Clutch | 430 Diaphragm type | |
| Steering | ZF technology | |
| Cab | X3000 mid-lengthened Cabin with A/C & single-sleeper | |
| Axle | Front axle | 9.5T MAN technology |
| Rear axle | 16Ton MAN casting axle, final ratio 4.769 | |
| Tire (radial tire) | 12.00R20 | |
| Oil tank | 400L(ALLOY) | |
Packaging and shipping
From the factory to the customer's destination, we will conduct all-around supervision. We can also help with purchase order contracts, test product quality, ensure timely delivery, and accommodate special orders.
Transportation: railway transportation, international direct transportation, including (international railway direct transportation, sea-rail combined transport, and sea-land multimodal transport.
Mode of transportation: container, LCL, FRC, roll-on-roll-off, bulk cargo, train transportation, truck, plane.
About us
We are a professional sales team, please tell us your needs, and we will recommend the most suitable truck configuration. We have a professional after-sales team that will solve your problems in time.
FAQ
1. Q: What kind of payment do you accept?
A: We accept T/T and L/C; other payments are negotiable.
2. Q: What is your minimum order quantity?
A: a unit Shacman 10 wheeler dump truck.
3. Q: What is your delivery time?
A: 30 days after receiving the deposit.
4. Q: What is the warranty time?
A: 12 months or 30,000 kilometers from the date of shipment, whichever comes first.
5. Q: What is your after-sales service?
A: We provide technical support for trucks and full life cycle parts supply.
